Ref. AG25/BDog Agility Course
Tunnel
Maison – Dog agility course
Tunnel House - Dog Agility Course: reassuring, durable tunnel for outdoor dog courses. Confidence, coordination and play.
- Warranty
- Up to 10 years
- Certification
- EN16630
Product view
- L 3.1 m
- P 1.3 m
- H 1.2 m
Overview
Tunnel Maison - Dog agility course
Tunnel Maison - Parcours Agility Chien is a covered passage module designed to boost your dog's confidence, coordination and concentration in real-life situations.
Its reassuring "house" silhouette makes the exercise intuitive for beginners and motivating for advanced levels. The HDPE tunnel body ensures smooth gliding and easy maintenance, while the powder-coated galvanized steel fronts and uprights, complemented by aluminum/stainless steel hardware, guarantee durability and weather resistance. Designed forpermanent outdoorinstallation, the AG25/B can be easily integrated into an existing dog run or installed as a stand-alone module in public parks, dog clubs, campsites and leisure areas. The tube's side openings allow light and ventilation, helping dogs to progress without apprehension. The exercise developsorientation, speed management and recall, with possible sequences in round trips or combined with other obstacles. Offered with layout advice, Tunnel Maison - Parcours Agility Chien is a robust, fun and safe solution for diversifying courses and providing a positive experience for all sizes.
Ref. AG25/B · Dog Agility Course
The figures
Technical specifications
Tunnel MaisonTechnical sheet · dimensions in mm
- Length
- 3,148
- Width
- 1,263
- Height
- 1,181
- Material
- Powder-coated steel
- Certification
- EN16630
- Warranty
- Up to 10 years
How to use it
Use
What it trains
Function
What the standard requires
Safety & use
Safety & use
- Minimum user height
- 140 cm
- Maximum user weight
- 150 kg
Putting it in place
Installation
- Safety areathe surface given in the table, clear all around.
- Concrete basepoured to the stated volume and depth, then cured.
- Fixingthe unit is bolted onto the cured base.
- Handoverplumb, tightness and no play before service.
- Upkeepregular visual check and periodic retightening (EN 16630).
Installation
- Concrete volume
- 0.384 m³
- Anchoring depth
- 600 mm
Built to last outdoors
Design & materials
- Galvanized steel structuresturdy frame treated against corrosion for optimum outdoor performance in all weather conditions.
- Multi-layer anti-corrosion coatingenhanced protection against moisture, UV and weathering, guaranteeing long life even in intensive use.
- Ergonomic house-shaped silhouettean intuitive design that reassures dogs from the very first approach and makes it easy to cross in a straight line without hesitation.
- Accessible surfaces are smooth and free of sharp edges to preserve the animal's physical integrity at every turn.
- Designed to withstand repeated use in collective environments, this module combines structural strength and active safety for years of maintenance-free use.
For whom, where
Recommended audience & environment
- Agility clubs and associations wishing to enrich their courses with a covered passage module accessible to all levels.
- Municipal dog parks and equipped dog parks offering structured educational activities for owners and their pets.
- Dog training centers and dressage schools integrating trust and orientation work into their training programs.
- Animal shelters and facilities using agility as a behavioral stimulation and socialization tool.
The Tunnel Maison fits perfectly into any outdoor dog agility course, whether for family fun or regular sports training. Its sturdy design and reassuring profile make it a must-have for collective dog areas.
What sets it apart
Built to last outdoors
In brief
Why choose Tunnel Maison?
The Tunnel Maison is the ideal module for developing your dog's confidence and fluidity of movement in covered passageways, right from the very first agility sessions. Its recognizable shape makes it easy for beginners to learn, while remaining motivating for experienced dogs. Suitable for specialized clubs and public dog parks alike. Designed by Herkules Fitness, it guarantees optimum durability and safety for intensive group use.
Downloads
Online fitness park configurator
The only manufacturer in France to offer an online configurator for outdoor fitness equipment. Select your equipment, visualize your project and receive a quote.
- 1 Choose your equipment
- 2 Visualize your layout
- 3 Check compliance
- 4 Receive your project
🛠 Launch configurator Free - No obligation - Immediate results
You may wonder
Frequently asked questions : Tunnel Maison
What benefits does the Home Tunnel bring to the dog during agility sessions?
Tunnel Maison simultaneously develops the dog's self-confidence, spatial orientation and concentration in a covered passage situation. By repeating the crossings, the animal improves its fluidity of movement and responsiveness to the handler's commands, two key agility skills.
Is this module suitable for dogs new to agility?
Yes, the house-shaped silhouette is designed to be intuitive and reassuring, making it an ideal entry point for novice dogs. The straight line crossing, with no bends or total darkness, makes for a gradual, stress-free learning curve for the animal.
What type of floor can the Tunnel Maison be installed on?
The Tunnel Maison is designed to be fixed to hard ground (concrete, asphalt) or compacted earth using the included anchoring plates. Installation on a flat, stable surface is recommended to guarantee the animal's safety when crossing at speed.
Is the module certified for use in public spaces?
Herkules Fitness equipment is designed and manufactured to the highest quality standards for outdoor community spaces. For any certification requirements specific to your municipal or community project, please contact our sales team for full technical documentation.
What are the dimensions of the Home Tunnel and what sizes of dog are it designed for?
The Tunnel Maison is designed to accommodate small to large dogs, covering the majority of agility breeds. To find out the exact dimensions (width, passage height and depth) adapted to your configuration, consult the technical data sheet available on the product page or contact our customer service department.
What maintenance does the Tunnel Maison require to maintain its performance over time?
Thanks to its anti-corrosion treatment in galvanized steel, the Tunnel Maison requires minimal maintenance: regular cleaning with water and periodic visual inspection of fasteners are all that's needed. Should the surface coating deteriorate, we recommend touching it up with a paint suitable for outdoor metal structures.
