Ref. AG29Dog Agility Course
A-Frame
Grand – Dog Agility Course
A-Frame Grand - Agility course for dogs: large A-frame, grippy surface. Confidence, coordination, long-lasting outdoor use.
- Warranty
- Up to 10 years
- Certification
- EN16630
Product view
- L 5.1 m
- P 0.3 m
- H 1.1 m
Overview
A-Frame Grand - Dog Agility Course
A-Frame Grand - Parcours Agility Chien is a large walkway designed to work on the dog's confidence, coordination and impulse power outdoors.
The ascent and descent are made on inclined planes that encourage fluid crossing and controlled speed management. Thanks to its stable, grippy walking surface, A-Frame Grand - Parcours Agility Chien lets you learn in safety: first at a slow pace with guidance, then more dynamically as you progress. The structure, designed for public use and permanent installation, combines weather-resistant materials (powder-coated metal uprights, anti-slip/PEHD wood-type technical panels, protected screws) for high durability and easy maintenance. Versatile, A-Frame Grand - Parcours Agility Chien can be integrated into any outdoor dog course and is suitable for communities, dog clubs, campsites and leisure areas. Used on its own as a learning module, or in combination with other obstacles (jump, slalom, tunnel), it enhances proprioception, support control and concentration, while building a clean technical movement (regular ascent, passage over the crest, controlled descent). A sure bet for a fun, progressive challenge for all sizes.
Ref. AG29 · Dog Agility Course
The figures
Technical specifications
A-Frame GrandTechnical sheet · dimensions in mm
- Length
- 5,060
- Width
- 300
- Height
- 1,067
- Material
- Galvanized powder-coated steel
- Certification
- EN16630
- Warranty
- Up to 10 years
How to use it
Use
What it trains
Function
What the standard requires
Safety & use
Safety & use
- Minimum user height
- 140 cm
- Maximum user weight
- 150 kg
Putting it in place
Installation
- Safety areathe surface given in the table, clear all around.
- Concrete basepoured to the stated volume and depth, then cured.
- Fixingthe unit is bolted onto the cured base.
- Handoverplumb, tightness and no play before service.
- Upkeepregular visual check and periodic retightening (EN 16630).
Installation
- Concrete volume
- 0.48 m³
- Anchoring depth
- 600 mm
Built to last outdoors
Design & materials
- Hot-dip galvanized steel structurein-depth anti-corrosion treatment for long-lasting resistance to weathering and outdoor humidity.
- Anti-slip ribbed surfacesthe inclined surfaces are equipped with a textured coating for optimum grip, even in wet weather.
- Secure edges and fasteningsno protruding parts likely to injure the animal, rust-resistant stainless steel bolts that can be inspected regularly.
- Baked-on polyester powder paint, resistant to UV and temperature variations.
- Designed for long-term installation in public outdoor environments, the A-Frame Grand combines robustness, animal safety and low maintenance over the long term.
For whom, where
Recommended audience & environment
- Canine areas in urban parks and municipal green spaces.
- Agility clubs and associations looking for fixed outdoor training equipment.
- Shelters and dog training centers to stimulate and socialize dogs.
- Allotments, residences or campsites with an area dedicated to dog activities.
The A-Frame Grand fits naturally into a complete dog agility course, offering owners and their companions professional equipment accessible to all levels, from beginners to regular practitioners.
What sets it apart
Built to last outdoors
In brief
Why choose A-Frame Grand?
The A-Frame Grand is the benchmark obstacle for developing dogs' confidence, coordination and balance on inclines, whatever their level. It is equally suited to agility clubs and public dog parks wishing to offer a complete and stimulating course. Its solid construction withstands intensive use and varied climatic conditions. Designed by Herkules Fitness, it guarantees maximum safety for the animal and exemplary durability for managers of public areas.
Downloads
Online fitness park configurator
The only manufacturer in France to offer an online configurator for outdoor fitness equipment. Select your equipment, visualize your project and receive a quote.
- 1 Choose your equipment
- 2 Visualize your layout
- 3 Check compliance
- 4 Receive your project
🛠 Launch configurator Free - No obligation - Immediate results
You may wonder
Frequently asked questions : A-Frame Grand
What concrete benefits does A-Frame Grand offer dogs?
The A-Frame Grand uses all the dog's muscles during ascent and descent, strengthening the front and rear limbs. It also develops proprioception, balance and self-confidence, essential qualities for progressing in agility.
Is this equipment suitable for beginners or experienced dogs only?
The A-Frame Grand is designed for all levels: beginners can tackle it gradually with the help of their master, working their way up and then down separately. Trained dogs can use it in rapid succession, making it a versatile obstacle suitable for a wide variety of canine profiles.
On what type of floor can this equipment be installed?
The equipment can be anchored to different types of ground: lawn, stabilized earth or concrete. Installation by grouting or bolted plates is recommended to guarantee the structure's stability, especially in areas frequented by large numbers of dogs.
Does the A-Frame Grand comply with safety standards for outdoor community equipment?
Herkules Fitness designs its equipment in line with the safety requirements applicable to collective outdoor facilities. Materials, fixings and finishes are selected to minimize any risk of injury to the animal and meet the expectations of public space managers.
What maintenance does this equipment require over time?
Low maintenance thanks to galvanized treatment and UV-resistant polyester paint. It is advisable to periodically check the tightness of the bolts, inspect the non-slip surfaces and clean the equipment with clear water to remove any build-up of dirt or foam.
What are the dimensions and maximum load-bearing capacity of the A-Frame Grand?
The A-Frame Grand is a large walkway designed to accommodate dogs of all sizes, including large breeds. For precise dimensions, frame weight and maximum recommended load, please contact the Herkules Fitness team, who will provide you with the full technical data sheet.
