Ref. SN-05 + SN-08 + SN-09Stainless steel fitness equipment
Surfer + Walker +
Twister – Stainless steel fitness equipment
Surfer + Walker + Twister Fitness Station Stainless Steel 316L. Compliant with EN16630, ideal for outdoor fitness in marine environments and humid areas.
- Warranty
- Up to 10 years
- Certification
- EN16630:2015
- Number of users
- 3
Product view
- L 2.5 m
- P 0.8 m
- H 1.2 m
Overview
Surfer + Walker + Twister - Stainless steel fitness equipment
Surfer + Walker + Twister - 316L Stainless Steel Fitness Station is a combined fitness apparatus offering a variety of exercises to improve mobility, stability, coordination, and overall physical fitness. Crafted from 316 stainless steel, these units perfectly withstand outdoor conditions, including saline environments, guaranteeing exceptional durability.
Ref. SN-05 + SN-08 + SN-09 · Stainless steel fitness equipment
The figures
Technical specifications
Surfer + Walker + TwisterTechnical sheet · dimensions in mm
- Length
- 2,507
- Width
- 825
- Height
- 1,230
- Safety area
- 3,825 × 5,507 mm · 18.11 m²
- Material
- Stainless steel
- Certification
- EN16630:2015
- Warranty
- Up to 10 years
How to use it
Use
What it trains
Function
What the standard requires
Safety & use
Safety & use
- Free fall height
- 410 mm
- Minimum user height
- 140 cm
- Maximum user weight
- 150 kg
- Number of users
- 3
Permitted surfacing
Putting it in place
Installation
- Safety areathe surface given in the table, clear all around.
- Concrete basepoured to the stated volume and depth, then cured.
- Fixingthe unit is bolted onto the cured base.
- Handoverplumb, tightness and no play before service.
- Upkeepregular visual check and periodic retightening (EN 16630).
Installation
- Concrete volume
- 0.327 m³
- Anchoring depth
- 600 mm
- Fixing
- Bolted
- Assembly
- To be assembled
Built to last outdoors
Design & Materials
- 316L Stainless Steel Construction:Each unit — Surfer, Walker, and Twister — is fully crafted from marine-grade 316L stainless steel, offering superior resistance to corrosion, oxidation, and harsh weather conditions including coastal and saline environments.
- Anti-Corrosion Treatment:The inherent chromium-nickel-molybdenum alloy composition of 316L steel provides a natural, self-renewing protective layer, eliminating the need for additional coatings while ensuring long-term structural integrity.
- Ergonomic Design:Each apparatus is engineered with user comfort in mind — smooth handlebar profiles, optimized range of motion, and non-slip foot platforms ensure safe and effective use for a wide range of body types and fitness levels.
- All moving parts are designed for fluid, low-maintenance operation, with sealed bearings and robust pivot joints that resist wear even under frequent public use.
- The combined station delivers a durable, vandal-resistant fitness solution built to last decades in demanding outdoor environments without compromising performance or aesthetics.
For whom, where
Recommended audiences & environments
- Seafront promenades and coastal parks:The 316L stainless steel construction makes this station the ideal choice for saline and humid environments where standard equipment would rapidly degrade.
- Public parks and urban fitness trails:Perfect for municipalities seeking multi-function fitness stations that serve diverse user profiles simultaneously, from seniors to active adults.
- Rehabilitation and wellness zones:The Surfer, Walker, and Twister each offer low-impact, joint-friendly exercises well-suited to post-rehabilitation programs or preventive wellness initiatives.
- Sports complexes and school campuses:Suitable for structured physical education or warm-up zones where mobility, coordination, and core strength are training priorities.
Whether installed along a beachfront boardwalk or within a city park fitness circuit, the Surfer + Walker + Twister Fitness Station Stainless Steel 316L adapts seamlessly to any outdoor public space. Discover our full range of outdoor fitness equipment designed for communities of all sizes.
What sets it apart
Built to last outdoors
In brief
Why choose the Surfer + Walker + Twister Station?
The Surfer + Walker + Twister Fitness Station Stainless Steel 316L offers a uniquely complete workout experience in a single, space-efficient installation, targeting hip mobility, cardiovascular endurance, and core strength all at once. Ideal for public spaces catering to mixed-age populations, it encourages daily physical activity in a safe and intuitive way. Designed by Herkules Fitness, it guarantees exceptional durability, minimal maintenance, and lasting performance even in the most demanding outdoor environments.
Downloads
Online fitness park configurator
The only manufacturer in France to offer an online configurator for outdoor fitness equipment. Select your equipment, visualize your project and receive a quote.
- 1 Choose your equipment
- 2 Visualize your layout
- 3 Check compliance
- 4 Receive your project
🛠 Launch configurator Free - No obligation - Immediate results
You may wonder
Frequently asked questions : Surfer + Walker + Twister
What muscle groups are targeted by the Surfer, Walker, and Twister combined station?
The three apparatuses complement each other to provide a full-body workout. The Surfer targets hip stabilizers and leg muscles, the Walker engages the quadriceps, glutes, and cardiovascular system, while the Twister focuses on the obliques, abdominal muscles, and lower back flexibility. Together, they cover mobility, strength, and endurance.
Is this fitness station suitable for seniors or users with limited mobility?
Yes, all three units are designed for low-impact use with smooth, controlled movements that are gentle on the joints. The Walker in particular mimics natural walking mechanics, making it highly accessible for seniors or users in rehabilitation. Handrails and stable foot platforms ensure safe use at all fitness levels.
Why is 316L stainless steel used instead of standard galvanized steel for this station?
316L stainless steel contains molybdenum, which provides significantly higher resistance to chloride corrosion compared to standard or galvanized steel. This makes it the preferred material for coastal installations, swimming pool surroundings, or any environment with elevated humidity or salt exposure, ensuring a much longer service life.
What type of foundation or ground preparation is required for installation?
The Surfer + Walker + Twister station is designed for in-ground concrete anchoring. A stable, level concrete foundation is required to ensure structural safety under dynamic loads. Herkules Fitness provides detailed installation specifications to ensure compliance with applicable outdoor fitness equipment standards.
Does this equipment meet European safety certifications for public outdoor fitness?
Yes, the station is designed and manufactured in accordance with EN 16630 standards governing fixed outdoor fitness equipment for public use. This ensures that structural integrity, safety clearances, and load capacities meet the requirements for installation in parks, schools, and other public spaces across Europe.
What maintenance is required to keep the station in good condition over time?
Thanks to its 316L stainless steel composition, the station requires minimal maintenance. Periodic visual inspections for mechanical wear, tightening of fasteners, and occasional cleaning with water are generally sufficient. Moving parts with sealed bearings are designed to operate reliably over years of intensive public use without requiring lubrication or part replacement under normal conditions.
