Ref. THJ-B02Classic fitness equipment
Pull – Outdoor Fitness Equipment
Rugged outdoor pullover, EN16630 standard, designed to develop upper-body strength outdoors.
- Warranty
- Up to 10 years
- Certification
- EN16630:2015
- Number of users
- 2
Product view
- L 2.6 m
- P 0.8 m
- H 2.0 m
Overview
Pull - Outdoor Fitness Equipment
The Herkules Fitness Classic Pullover is outdoor fitness equipment designed to be used by two people simultaneously.
It strengthens back, shoulder and arm muscles, while improving coordination and posture. It allows users to work together, making training more motivating and user-friendly, while enjoying the benefits of outdoor fitness by building upper-body muscle strength. Designed for outdoor use, the Pull offers stimulating activity, improving coordination, posture and muscle strength in the back, shoulders and arms. They're perfect for varying workouts while enjoying the benefits of outdoor fitness. From strengthening back, shoulder and arm muscles to improving posture, the Pull is perfect for parks, fitness trails and leisure areas. This outdoor fitness equipment is suitable for all fitness levels and is designed to withstand outdoor conditions, offering an enjoyable and user-friendly outdoor fitness experience.
Ref. THJ-B02 · Classic fitness equipment
The figures
Technical specifications
Footprint
- Length
- 2,631 mm
- Width
- 772 mm
- Height
- 1,957 mm
- Safety area
- 5,631 × 3,772 mm (21.24 m²)
Material & compliance
- Material
- Galvanized powder-coated steel
- Certification
- EN16630:2015
- Warranty
- Up to 10 years
- L 2.6 m
- P 0.8 m
- H 2.0 m
How to use it
Use
What it trains
Function
What the standard requires
Safety & use
Safety & use
- Free fall height
- 550 mm
- Minimum user height
- 140 cm
- Maximum user weight
- 150 kg
- Number of users
- 2
Permitted surfacing
Putting it in place
Installation
- Safety areathe surface given in the table, clear all around.
- Concrete basepoured to the stated volume and depth, then cured.
- Fixingthe unit is bolted onto the cured base.
- Handoverplumb, tightness and no play before service.
- Upkeepregular visual check and periodic retightening (EN 16630).
Installation
- Concrete volume
- 0.28 m³
- Anchoring depth
- 600 mm
- Fixing
- Bolted
- Assembly
- To be assembled
Built to last outdoors
Design & materials
- Galvanized steel structurethe main frame is made of hot-dip galvanized steel, offering optimum resistance to weather and temperature variations.
- Enhanced anti-corrosion treatmenta coat of epoxy polyester paint applied by powder coating provides lasting protection against rust, UV and humidity.
- Ergonomic handlesthe handles are designed to ensure a comfortable, secure grip, reducing muscle fatigue during repeated sets.
- Seats and contact surfaces are treated to withstand the intensive wear and tear of use in public spaces.
- The overall design ensures exceptional long-term durability, even in demanding urban environments.
For whom, where
Recommended audience & environment
- Urban parks and municipal green spaces offering fitness facilities accessible to all ages.
- Residences and condominiums with shared outdoor spaces to enhance residents' well-being.
- Schools, colleges and high schools with fitness zones in their courtyards or outdoor sports areas.
- Leisure centers, campsites and sports clubs looking to expand their range of outdoor physical activities.
The Pull fits perfectly into any outdoor fitness environment, whether it's a complete sports area or a fitness trail. Its two-seater format encourages duo practice and strengthens social ties within communities.
What sets it apart
Built to last outdoors
In brief
Why choose the Pull?
The Pull is the ideal machine for effectively strengthening back, shoulder and arm muscles in a friendly outdoor setting. Its two-seater design encourages group practice, making it a perfect choice for communities, public parks and shared sports areas. It can be used by beginners and regular exercisers alike, thanks to its intuitive, guided movement. Designed by Herkules Fitness, it guarantees robustness, safety and longevity in all outdoor environments.
Downloads
Online fitness park configurator
The only manufacturer in France to offer an online configurator for outdoor fitness equipment. Select your equipment, visualize your project and receive a quote.
- 1 Choose your equipment
- 2 Visualize your layout
- 3 Check compliance
- 4 Receive your project
🛠 Launch configurator Free - No obligation - Immediate results
You may wonder
Frequently asked questions : Pull
Which muscles are most involved in the Pull?
The Pull primarily targets the muscles of the back, notably the latissimus dorsi and trapezius, as well as the shoulders and biceps. The horizontal pulling movement also encourages work of the rhomboids, helping to improve users' overall posture.
Can the Pullover be used by people of all ages?
Yes, the Pull is designed to suit a wide audience, from teenagers to senior citizens, thanks to its guided movement and natural resistance. However, it is recommended that young children practice under adult supervision to ensure good posture and avoid any risk of injury.
What type of floor is required for Pull installation?
The Pull can be installed on various types of ground, including concrete, asphalt or stabilized soil. A solid foundation is essential to ensure the unit's stability. We recommend that you call in a qualified professional to carry out the anchoring according to the technical recommendations supplied by Herkules Fitness.
Is the Puller certified for use in public spaces?
Yes, the Pull - outdoor fitness equipment from Herkules Fitness is designed and manufactured in compliance with current European standards for outdoor sports equipment for collective use, in particular EN 16630. This compliance guarantees the safety of users in public areas.
What are the maintenance requirements for this device?
The Pull requires minimal maintenance thanks to its weather-resistant materials. Regular visual inspection of assemblies, handles and seats is recommended, along with periodic cleaning with clear water. In the event of wear or damage to a component, we recommend rapid replacement.
What is the maximum load capacity of the Pull?
The Pull is dimensioned to support the weight of two adult users simultaneously, in compliance with the requirements of the standards applicable to collective outdoor fitness equipment. For precise technical specifications, including maximum approved load, please consult the full product data sheet or contact our team directly.
